Compact, quiet and versatile – The three super-slim ceiling fans of the Petite series made by renowned US brand Westinghouse have a 76cm / 30inch diameter and are perfect for indoor rooms sized 10m2 or less. The available housing colours brushed nickel, antique brass and white are complemented by six colour-coordinated reversible blades. They achieve up to 273 revolutions per minute running clockwise (winter use) and counterclockwise. On top of bringing you year-round convenience the Petite fan comes with a single-light fixture with a high-quality frosted glass. The light and three fan speeds are controlled with the included pull cords - a wall controller from our range can be added for maximum comfort. The Petite ceiling fan operates on a whisper-quiet noise level, therefore it is a great choice for bedrooms and offices as well.
Westinghouse Petite – small ceiling fan, high efficiency!
Our product choice for you
Technical data of the Petite series outlined:
- 230 Volt / 50 Hertz
- Diameter: 76cm (30“) for rooms with up to 10 sqm (107 sqft) size
- Housing colours: brushed nickel, antique brass
- 6 reversible blades
- Blade colours*: wengue/rosewood, oak/walnut
- Revolutions per minute: 177 / 230 / 273
- Motor wattage: 26.8 / 37.9 / 52.4 W
- Blade pitch: 18°
- Ceiling to blades: 15.6cm (16.15“)
- Total height: 32cm (12“)
- Diameter motor housing: 23.8cm (9“)
- Forward and reverse function (summer and winter mode)
- Individual pull cords for light and fan
- Wall controller can be added
- Very smooth and quiet operation, max. 45dB(A)
- Weight: 4.7kg (10.3lbs)
It is up to you what type of bulb you are using for the light fixture of the Petite ceiling fan, including popular LED lamps that are known for their durable and energy-efficient properties. Replacing the lamps is no different from changing the bulb in a normal ceiling light. The process is explained in detail in the instruction manual of the Petite. As a precautionary measure it is recommended to cut off the power supply (ideally directly on the fuxe box). Afterwards the mushroom glass can be removed without much effort. Leave the bulb enough time to cool down completely before touching it to prevent bodily harm.
Lighting: 1 x E27 Type A15, max. 60 Watt (bulb not included in the delivery)
- The lumaire is suitable for bulbs rated energy classes A++ to E!
The Petite hugger-mount fan is perfect for use in rooms with low or suspended ceilings. A minimum distance of 2.30 metres between the floor and the fan blades should still be maintained, though. Thanks to a powerful motor that reaches 273 revolutions per minute this distance is more than enough to create sufficient air circulation.
All benefits of the Petite series at a glance:
- ideal size for rooms with low ceilings
- compact design for small rooms
- elegant reversible blades with a wooden or white finish
- three fan speeds for maximum convenience
- max. power consumption 52.4 Watt and 273 revolutions per minute
- use all year round
- reduce heating costs with heat recovery
- very quiet top-quality motor, suitable for bedrooms
- manufacturer’s warranty on the motor: 10 years
- light and fan are controlled individually
- includes pull cords (wall controller can be added)
Application
- all indoor areas with up to 10m2 size
- guestrooms
- small bedrooms
- corridor, entrance
- private workspace, computer lab
- children’s bedroom
The reverse winter function, meaning taking in cold air from the ground to mix it with the layer of warm air above. The Petite fulfils all requirements just as much as bigger models, however due to its small size it is more suitable for small rooms. Three speed settings give you the option of adjusting the airflow to the individual situation and to your needs. Despite the velocity the Petite will never create draught, even when using the reverse function (running clockwise). The running direction can be changed by using a slide switch that is located on the motor housing. Depending on the rotation speed the ceiling fan’s power consumption varies but never exceeds 52.4 Watt (not taking account of the lighting).
The Petite ceiling fan can be mounted to all common building materials (except sloping ceilings) thanks to a total weight of ca. 4.7kg. This fan gives you a lot of freedom when it comes to furnishing your interior and making it part of the interior.
The Petite ceiling fan meets both practical and aesthetic demands. On one hand the technical equipment, e.g. reverse winter function, whisper quiet top-quality motor and sleek light fixture leave nothing to be desired. Furthermore, its compact size and slim overall height are other benefits speaking in favour of this device. On top of that the Petite comes with reversible wooden blades that are finished with two colours to help you match your decor. The specific wood grain is imitated to resemble the individual timber, adding a natural look to your home.
*= blades made of medium-density fibreboard (MDF) with a finish in the specified colour
Maple / White discontinued
The installation of the blades is described step by step in the instruction manual. You can always refer to the manual when you feel like turning over the blades to change the visible colour. Noise-reducing gaskets for mounting the blades to the motor housing are included in the delivery.
Go by your personal taste when choosing the housing. White lacquered metal is ideal for light-coloured interiors, on the other hand it can also act as a contrast to strong colours on the wall and ceilings. The nickel model has a slightly metallic shine that enhances the brushed finish. The antique brass colour is a classic and goes very well with conventional oak and walnut furniture.
Using the pull cords: Turning the Petite ceiling fan on/off and selecting the rotation speeds is done with a pull cord. Pulling it once starts the fan on the highest speed setting with 273 rpm, pulling it twice slows it down to medium speed on 230 rpm and finally, pulling it a third time activates low speed with 177 rpm. The fan is turned off by pulling it once more, that is four times in total.
Safety instructions: The ceiling fans of the Petite range are rated with an IP20 protection. There is a protection against contact with the conductive parts (electrical parts) and ingress of solid foreign objects above 12.5mm diameter (your fingers, for example). It goes without saying that the fan blades should not be touched when rotating. However, the fan is not protected against water and humidity as you might encounter in bathrooms. Therefore the Petite ceiling fan can only be used in rooms with a common maximum humidity level of 60%. The ceiling fan is put up by a professional electrician.
Accessories:
Manufacturer: Westinghouse is a pioneer in the field of electric lighting and has specialised in ceiling fans both with and without light fixtures under the name Westinghouse Lighting. The US-based brand quickly noticed how important it is to build a relationship with customers based on trust and quality of products – particularly in our fast-paced modern life.
